Ranges: 0 to 0.1 bar and up to 0 to 6 bar
Working temperature: -15 to 80°C
Media material: ceramic and 1.4305 stainless steel (AISI 303)
Accuracy: 0.5% FS including hysteresis, linearity and repeatability
Pressure connection: 1/8" thread or push-on spigot
System pressure: 25 bar to pressure range 10 bar. 50 for pressure range 25 bar
Rupture pressure: 1.5X system pressure
Electrical connector: DIN 43650-A, IP65 or cable gland with 1.5m cable
Output: two-wire 4-20mA. Other signals under request
Electromagnetic compatibility: CE conformity to EC directive 89/336
Power supply: 11 to 33Vdc
Dimensions: Ø 45 x 89mm
