Alarm output |
no |
|
Ambient temperature |
0 - 50°C |
|
Beam spot range |
3.14 - 0.79mm² |
|
Coating housing |
Anodised |
|
Construction type housing |
Cuboid |
|
Degree of protection (IP) |
IP67 |
|
Distance laser focus |
130mm |
|
Distance teach-in limits |
3mm |
|
Geometrical resolution |
0.06mm |
|
Height of sensor |
65mm |
|
Increased ambient temperature >70°C |
no |
|
Laser focus beam spot |
0.79mm² |
|
Laser protection class |
Class 2 |
|
Length of sensor |
50mm |
|
Linearity deviation |
0.02 - 0.2mm |
|
Material housing |
Zinc die-cast |
|
Material of optical surface |
Glass |
|
Measuring principle for optical distance measurement |
Triangulation |
|
Measuring range length |
30 - 130mm |
|
No load current |
100mA |
|
Number of poles |
5 |
|
Operating voltage |
12 - 28 |
|
Reflector included |
no |
|
Relative linearity deflection |
0.15% |
|
Resolution |
0.06mm |
|
Response-/decay time |
0.9ms |
|
Reverse polarity protection |
yes |
|
Scanning principle |
Push button |
|
Setting procedure |
Teach-In |
|
Shape of light beam |
Point |
|
Short-circuit-proof |
yes |
|
Small light beam diameter |
no |
|
Supply voltage |
12 - 28V |
|
Type of analogy output |
4 mA ... 20 mA |
|
Type of electric connection |
Connector M12 |
|
Type of light |
Laser diode, red light |
|
Voltage type |
DC |
|
Wavelength of the sensor |
650nm |
|
Width sensor |
20.6mm |
|
With LED indication |
yes |
