• Accepts thermocouples J, K, T and Pt100 RTD without any hardware change or recalibration

• Auto tuning PID

• Output: 2 relays SPST 1,5 A, 1 relay SPDT 3 A and 5 Vcc logic pulse (ideal for enabling Solid State Relays)

• The outputs are programmable for main control or alarm

• Alarm functions: low, high, differential, low differential, high differential, sensor break

• Two alarm functions can be directed to one single output

• Switching power supply 100~240 Vac, 24 Vdc optional

• Safe output function allows the user to set control output conditions in case of sensor break or failure

• Digital input

• Simplified programming menu makes operator programming easily

• Indelible electronic serial number with 8 digits can be accessed from the display

• Count up and countdown timer

• Adjustable break timing until 99:59 (mm:ss)

• Timer enabling through digital input, Set Point, keypad or by enabling the temperature control

• Timer output can be switched when the time finishes

• Silicone rubber keypad

• Front panel protecion: IP65

• CE and UL certification
