Ambient temperature |
-25 - 70°C |
|
Cascadable |
no |
|
Coating housing |
Nickel-plated |
|
Compression-resistant |
no |
|
Connection to an amplifier |
no |
|
Construction type housing |
Cylinder, screw-thread |
|
Correction factor (aluminium) |
0.3 |
|
Correction factor (brass) |
0.4 |
|
Correction factor (copper) |
0.2 |
|
Correction factor (stainless steel) |
0.7 |
|
Correction factor (steel) |
1 |
|
Degree of protection (IP) |
IP67 |
|
Hysteresis |
15% |
|
Increased sensing range |
no |
|
Length of sensor |
45mm |
|
Material active area of sensor |
PBT |
|
Material housing |
Metal |
|
Material housing |
Brass |
|
Max. output current |
200mA |
|
Mechanical mounting condition for sensor |
Concise |
|
No load current |
15mA |
|
Norm trimming plate |
12x12x1mm |
|
Number of poles |
3 |
|
Pitch thread |
1mm |
|
Rated control supply voltage Us at DC |
10 - 30V |
|
Relative repeat accuracy |
10% |
|
Reverse polarity protection |
yes |
|
Short-circuit-proof |
yes |
|
Suited for safety functions |
no |
|
Supply voltage |
10 - 30V |
|
Switching distance |
2mm |
|
Switching frequency |
800Hz |
|
Thread length |
23mm |
|
Thread size metric (M..) |
12 |
|
Type of electric connection |
Connector M12 |
|
Type of switch function |
Normally open contact |
|
Type of switching output |
PNP |
|
Voltage drop |
2V |
|
Voltage type |
DC |
|
With LED indication |
yes |
|
With monitoring function downstream switching devices |
no |
