• Analog inputs: programmable for thermocouples

•

• (J, K, T, E, N, R, S, B), Pt100, mV, V, mA



  Cold junction compensation for thermocouples and

•

• compensation for Pt100 3-wire cables



  Open loop detection for thermocouples, Pt100 and mV



  Sampling rate for 1 analog input: 10Hz for mV, V and mA. 5 Hz

•

• for t thermocouples and Pt100



  Analog input resolution: 17 bits



  Digital inputs: in voltage, 4 to 35 V to activate. Internally

•

• limited current in 5 mA



  Digital outputs: 8 A / 250 Vac SPDT relay, resistive load



  Power: 10 to 35 Vdc,  50 mA maximum current



  2-wire RS485 communication with Modbus RTU protocol.

•

• Configurable address and baud rate



  (1,200 to 115,200bps)



  LED indicators for communication and status



  Key for resetting communication parameters to

•

• original factory default



  Accuracy (at 25 °C): Pt100, mV, V and mA: ±0.15 % of full

•

• scale. Thermocouples: ±0.25 % of full scale

Temperature effect: 0.003 % of full

•

• scale/°C



  Cold junction compensation for thermocouples:

•

• 1 °C at 25 °C. ±0.05 °C / °C



  Isolation: 1000 Vac from inputs (analog or digital) and power

•

• or communication



  Windows based configurator software



  Dimentions: 72 x 78 x 19 mm



  Mounting: 35 mm DIN rail



  Working temperature: 0 to 70 °C
